Neulog Galvanic Skin Response (GSR) Sensor NUL-217
Item # NL-2170
The Galvanic Skin Response (GSR) logger sensor measures the conductivity of our skin, especially between our hand fingers.
Other Options
| Order Qty |
Price | Qty for Discount |
Discount Price |
Total Savings |
||||
|---|---|---|---|---|---|---|---|---|
|
Neulog Anemometer Sensor NUL-242 Item # NL-2420 |
|
|
$149.95 | ||||
|
Neulog Barometer Sensor NUL-221 Item # NL-2210 |
|
|
$92.95 | ||||
|
Neulog Hand Dynamometer Sensor NUL-237 Item # NL-2370 |
|
|
$159.95 | ||||
|
Neulog Light Sensor NUL-204 Item # NL-2040 |
|
|
$69.95 | ||||
|
Neulog Oxygen Sensor NUL-205 Item # NL-2050 |
|
|
$249.95 | ||||
|
Neulog Pressure Sensor NUL-210 Item # NL-2100 |
|
|
$94.95 | ||||
|
Neulog Pulse Sensor NUL-208 Item # NL-2080 |
|
|
$79.95 | ||||
|
Neulog Soil Moisture Sensor NUL-229 Item # NL-2290 |
|
|
$124.95 | ||||
|
Neulog Spirometer Sensor NUL-216 Item # NL-2160 |
|
|
$175.95 | ||||
|
Neulog Surface Temperature Sensor NUL-233 Item # NL-2330 |
|
|
$39.95 | ||||
|
Neulog Temperature Sensor NUL-203 Item # NL-2030 |
|
|
$49.95 | ||||
|
Neulog Turbidity Sensor NUL-231 Item # NL-2310 |
|
|
$129.95 | ||||
Additional Details
The Galvanic Skin Response (GSR) logger sensor measures the conductivity of our skin, especially between our hand fingers. The conductivity of our skin changes according to unconscious emotion effects such as sudden noise, smell, touch, pain or view. This sensor has two ranges: conductivity in micro Siemens and arbitrary numbers.
Specifications:
Experiment Duration: 1 second to 31 days.
Range and operation modes: 0-10 μS 0-65,279 Arbitrary units
ADC resolution: 16 bit
Resolution: 10 nS
Max Sample Rate (S/sec): 100
Note: The skin response time from the sudden effect is between 0.1 to 0.8 seconds. The level of the response changes dramatically from one person to another. The user must put his hand on a table, chair or on his lap and be still.
Please note: A connection between your sensors and hardware is required. You can choose from the USB Module, WiFi Module, RF Module, or Display Module. A Battery Module is also required for any connection other then USB Module, which is powered through the cable. View the Neulog Connection Interface Group for accessories.
Products being sold are not toys. They are for Educational / Laboratory use only. They are not for use by children 12 and under.
Resources
Accessories
| Order Qty | Price | Qty for Discount | Discount Price | Total Savings | ||||
|---|---|---|---|---|---|---|---|---|
|
Neulog USB Module USB-200 Item # NL-2003 |
|
|
$59.95 | ||||
|
Neulog Rechargeable Battery Module BAT-200 Item # NL-2002 |
|
|
$49.95 | ||||
|
Neulog WiFi Module WIFI-202 Item # NL-2005 |
|
|
$172.95 | ||||
|
Neulog Bluetooth Connection Module Item # NL-0202 |
|
|
$129.00 | ||||
|
Neulog Viewer Display Module VIEW-200 Item # NL-2000 |
|
|
$66.95 | ||||
|
Neulog Viewer Graphic Color Display Module VIEW-101 Item # NL-2001 |
|
|
$174.95 | ||||
